🤖 AlexFreqAlphaDeck - Complete Installation Guide

Complete Docker-based deployment package for the Freqtrade Multi-Bot Dashboard

---

📋 Table of Contents

• Overview
• System Requirements
• Quick Start
• Installation Methods
• Configuration
• Database Schema
• Usage
• Troubleshooting
• Security
• Upgrading

---

🎯 Overview

Multibotdashboard V10 is a modern, real-time dashboard for monitoring and controlling multiple Freqtrade trading bots from a single interface.

✨ Features

• Multi-Bot Management - Monitor unlimited Freqtrade bots from one dashboard
• Real-Time Updates - Live WebSocket data streaming
• Auto-Discovery - Automatically detects bots via Docker or filesystem
• Portfolio Analytics - Aggregated performance metrics
• Trade History - Detailed logs with filtering and export
• Health Monitoring - Track uptime, latency, and errors
• Dark/Light Mode - Beautiful responsive UI
• Mobile Ready - Works on desktop and mobile

🏗️ Architecture

┌─────────────────────────────────────────────────────────────────────────┐
│                              CLIENT                                      │
│                     (Browser / Mobile App)                               │
└─────────────────────────────┬───────────────────────────────────────────┘
                              │ HTTP / WebSocket
┌─────────────────────────────▼───────────────────────────────────────────┐
│                           FRONTEND                                       │
│              React 18 + TypeScript + Vite + Tailwind CSS                 │
│                         Port: 5000                                       │
└─────────────────────────────┬───────────────────────────────────────────┘
                              │ REST API / WebSocket
┌─────────────────────────────▼───────────────────────────────────────────┐
│                           BACKEND                                        │
│              FastAPI + Python 3.11 + SQLAlchemy 2.0                      │
│                         Port: 8000                                       │
└─────────────────────────────┬───────────────────────────────────────────┘
              ┌───────────────┼───────────────┐
              │               │               │
┌─────────────▼─────┐ ┌───────▼────────┐ ┌────▼──────────┐
│   PostgreSQL      │ │   PostgreSQL   │ │    Redis      │
│   (Main DB)       │ │  (Analytics)   │ │   (Cache)     │
│   Port: 5432      │ │   Port: 5433   │ │  Port: 6379   │
└───────────────────┘ └────────────────┘ └───────────────┘

---

💻 System Requirements

Minimum Requirements

| Component | Minimum | Recommended | |-----------|---------|-------------| | CPU | 2 cores | 4+ cores | | RAM | 4 GB | 8+ GB | | Disk | 20 GB | 50+ GB SSD | | OS | Linux/macOS/Windows with Docker | Linux Ubuntu 22.04+ | | Docker | 20.10+ | Latest | | Docker Compose | 2.0+ | Latest |

Network Requirements

• Ports to open:
  • 5000 - Dashboard UI
  • 8000 - API (if accessing directly)
  • 8090 - Adminer (optional, internal only recommended)

---

🚀 Quick Start

1. Clone/Download

# Clone the repository
git clone https://github.com/yourusername/multibotdashboard-v10.git
cd multibotdashboard-v10

# OR download and extract the release
wget https://github.com/yourusername/multibotdashboard-v10/releases/download/v10.0.0/multibotdashboard-v10.tar.gz
tar -xzf multibotdashboard-v10.tar.gz
cd multibotdashboard-v10

2. Run Installation

# Make install script executable
chmod +x install.sh

# Run interactive installation
./install.sh

# OR with custom options
./install.sh --db-password mypass --admin-password myadmin --production

3. Access Dashboard

🌐 Dashboard UI:    http://localhost:5000
📚 API Docs:        http://localhost:8000/docs
🗄️  Adminer (DB):   http://localhost:8090

Default Login:

• Username: admin
• Password: admin (change immediately!)

---

🔧 Installation Methods

Method 1: Automated Installation (Recommended)

./install.sh

This will:

1. Check prerequisites (Docker, Docker Compose)
2. Generate secure passwords and secrets
3. Create directory structure
4. Set up database schemas
5. Build and start all services

Method 2: Manual Installation

# 1. Create environment file
cp .env.example .env
nano .env  # Edit with your settings

# 2. Create directories
mkdir -p {logs,backup_DB,data,db/init,db/init-analytics}

# 3. Start databases first
docker-compose up -d postgres postgres-analytics redis

# 4. Wait for DB initialization (30 seconds)
sleep 30

# 5. Start all services
docker-compose up -d

Method 3: Production Deployment

# Production mode with custom domain
./install.sh \
  --production \
  --db-password "$(openssl rand -base64 32)" \
  --jwt-secret "$(openssl rand -hex 64)" \
  --admin-password "$(openssl rand -base64 16)"

---

⚙️ Configuration

Environment Variables

All configuration is done via the .env file:

| Variable | Description | Default | |----------|-------------|---------| | PUBLIC_HOST | Public hostname/IP | localhost | | DB_PASSWORD | PostgreSQL password | (auto-generated) | | JWT_SECRET | JWT signing key | (auto-generated) | | ADMIN_USERNAME | Admin username | admin | | ADMIN_PASSWORD | Admin password | admin | | BACKEND_PORT | API port | 8000 | | FRONTEND_PORT | UI port | 5000 | | REDIS_PORT | Redis port | 6379 |

Docker Compose Configuration

Key settings in docker-compose.yml:

# All volumes are mounted as RW (read-write) as requested
volumes:
  - /var/run/docker.sock:/var/run/docker.sock:rw  # Docker access
  - /opt:/opt:rw                                    # Freqtrade data
  - ./backend/src:/app/src:rw                      # Backend code
  - ./config:/app/config:rw                        # Config files

Dashboard YAML Config

Create config/dashboard.yaml:

server:
  host: "0.0.0.0"
  port: 8000
  cors_origins:
    - "http://localhost:5000"

database:
  url: "postgresql://dashboard:dashboard@postgres:5432/dashboard"

discovery:
  docker:
    enabled: true
    image_patterns:
      - "freqtradeorg/freqtrade"
  filesystem:
    enabled: true
    scan_paths:
      - "/opt/freqtrade/*/user_data"

api_defaults:
  username: "your_freqtrade_user"
  password: "your_freqtrade_pass"

---

🗄️ Database Schema

Main Dashboard Database (dashboard)

| Table | Purpose | |-------|---------| | users | User accounts and authentication | | bots | Registered Freqtrade bots | | bot_snapshots | Historical bot metrics | | trades | Trade history from all bots | | alerts | System alerts and notifications | | settings | Application configuration | | audit_log | Activity tracking |

Analytics Database (freqtrade_analytics)

| Table | Purpose | |-------|---------| | crypto_prices | Market price data | | crypto_movers | Top gainers/losers | | stocks | Stock market data | | portfolio_snapshots | Aggregated portfolio metrics | | portfolio_trades | Cross-bot trade history | | news | Market news and sentiment | | economic_indicators | Economic data | | daily_performance | Daily profit/loss tracking |

---

🎮 Usage

First Login

1. Navigate to http://localhost:5000
2. Login with default credentials
3. Immediately change the admin password!
4. Go to Settings → Profile → Change Password

Adding Bots

Method 1: Auto-Discovery

• Dashboard automatically scans for bots every 60 seconds
• Ensure your bots are running in Docker or accessible in scan paths

Method 2: Manual Registration

1. Go to Bots → Add Bot
2. Enter bot details:
   • Name: Unique identifier
   • API URL: http://bot-host:8080
   • Username/Password: Freqtrade API credentials
3. Click "Test Connection" then "Save"

Dashboard Views

| View | Description | |------|-------------| | Overview | Portfolio summary, P&L, active bots | | Bots | Individual bot status and controls | | Trades | Trade history with filters | | Analytics | Charts and performance metrics | | Alerts | System notifications | | Settings | Configuration and user management |

---

🔍 Troubleshooting

Container Won't Start

# Check logs
docker-compose logs -f [service_name]

# Common fixes
docker-compose down
docker-compose pull
docker-compose up -d

Database Connection Issues

# Check database health
docker-compose exec postgres pg_isready -U dashboard

# Reset databases (WARNING: data loss!)
docker-compose down -v
docker-compose up -d postgres postgres-analytics

Bot Discovery Not Working

# Check Docker socket access
docker-compose exec backend docker ps

# Verify scan paths
docker-compose exec backend ls -la /opt

Common Errors

| Error | Solution | |-------|----------| | Connection refused | Wait for services to start (30s) | | Permission denied | Check volume permissions: chmod -R 755 data/ | | JWT validation failed | Regenerate JWT_SECRET in .env | | Database locked | Restart postgres: docker-compose restart postgres |

---

🔒 Security

Production Checklist

• [ ] Change default admin password
• [ ] Generate strong JWT_SECRET
• [ ] Use strong DB_PASSWORD
• [ ] Enable HTTPS (reverse proxy)
• [ ] Restrict Adminer access (
