General

This Python package is used for generating HTML reports about the contents of Esri geodatabases. It supports working with Esri personal/file geodatabases as well as RDBMS enterprise geodatabases (however, it also works with RDBMS databases that were not geodatabase enabled).

Example of report:

Sample report

Usage guidelines

In order to use this tool, you would need to have either:

ArcGIS Desktop, ArcGIS Server or ArcGIS Pro installed (for arcpy package). You will be able to run the tool with ArcGIS Desktop/Server Python 2.7 as well as ArcGIS Pro Python 3.5+.
GDAL (for ogr package). This means you will be able to run the tool without having any Esri software installed. However, only file geodatabases are supported for reporting with GDAL.

The code written is a valid Python 2 as well as Python 3 code, so using the tool in both environments is supported. You will need pandas and beatifulSoup Python packages which can be installed from pip if you are ArcGIS Desktop/Server user or using conda if you are ArcGIS Pro or Anaconda user. See Installing Packages in the Python documentation (for ArcGIS Desktop users) and Install a package in the Conda documentation (for ArcGIS Pro and Anaconda users) to get help.

If the package is able to import arcpy, then it will use arcpy because it provides a more complete view into your geodatabase. The most time is spent in arcpy describe and listing functions iterating the datasets and pulling all the relevant information.

If arcpy is not found in your system, then the package will try to import ogr. The OpenFileGDB driver is used to access the key information about the geodatabase and its items. Please keep in mind that when using ogr, no information about tables/feature classes indexes and subtypes will be reported and many of the ArcGIS specific properties won't be shown either.

Output report

After HTML file is generated, you can open it in a web browser. The HTML file uses resources in other folders located in the app folder which means you cannot move the HTML file somewhere else without copying its dependency folders. If you would like to move the report somewhere else, you need to copy the whole app folder. While having the HTML file shown in a web browser, you can use the links to navigate throughout the page. Keep in mind that since navigation is built using the headers id, you can use the web browser's tools for navigating forward and back as you navigate between different sections of the report.

Requirements

arcpy | GDAL 2.1.0
Python 2.7 | 3.5
pandas >= 0.20.1
beautifulsoup4 >= 4.6.0

Installation

python setup.py install

Please keep in mind that arcpy and GDAL won't be installed when installing the package. The arcpy package can be obtained by installing ArcGIS software and GDAL can be installed in many ways, for instance, using Anaconda Navigator or using a binary wheel.

Getting started

When creating a Reporter class, you'd need to supply path to your geodatabase and output folder for report data files. Then, calling Reporter.gdb2html() would let you optionally specify what information you would like to include into your output HTML report. Depending on the geodatabase size, number of chosen items to include in the report as well as the available system resources, it might take some minutes to run.

The package has convenience functions which can be used to specify what exactly do you want to generate report for. The gdb2html function will create a complete report. This function provides you with fine-grained control over what information will be included in the report, so you can use it providing booleans arguments (for instance, you may want to get only list of tables and feature classes without reporting their fields, subtypes, and indexes). However, you can specify if you want to report only domains, only tables, or only feature classes using the domains2html, tables2html, and fcs2html functions respectively.

To generate full geodatabase report:

import registrant
reporter = registrant.Reporter(
    r"C:\GIS\Production.gdb", r"C:\GIS\ReportFolder"
)
reporter.gdb2html()
print(reporter.report_file_path)

To generate report listing only tables and feature classes (with no information on fields, subtypes, and indexes):

import registrant
reporter = registrant.Reporter(
    r"C:\GIS\Production.gdb", r"C:\GIS\ReportFolder"
)
reporter.gdb2html(
    do_report_versions=False,
    do_report_replicas=False,
    do_report_domains=False,
    do_report_domains_coded_values=False,
    do_report_relclasses=False,
    do_report_tables=True,
    do_report_tables_fields=False,
    do_report_tables_subtypes=False,
    do_report_tables_indexes=False,
    do_report_fcs=True,
    do_report_fcs_fields=False,
    do_report_fcs_subtypes=False,
    do_report_fcs_indexes=False,
)
print(reporter.report_file_path)

To generate report listing only domains and coded values for domains:

import registrant
reporter = registrant.Reporter(
    r"C:\GIS\Production.gdb", r"C:\GIS\ReportFolder"
)
registrant.domains2html()

Architecture

This tool uses arcpy package (and if you don't have any ArcGIS software installed - ogr package) to read properties of geodatabase into Python dictionaries which are used then to construct pandas data frames. The data frames are exported into HTML tables (as large strings) using built-in pandas.DataFrame.to_html method. To merge all the HTML tables into a single page, beatifulSoup package is used. The HTML report page is built using the Bootstrap 3 Dashboard sample. Some extra functionality is added with the help of Bootstrap 3 DataTables extension. Additional navigation items in the table of contents are added to the HTML page on-the-fly while reading geodatabase tables and feature classes.

FAQ

Why not just use ArcGIS Diagrammer to generate HTML reports?

ArcGIS Diagrammer was deprecated at ArcGIS 10.3 which means only users of ArcGIS 10.0-10.2 can use it. If you have ArcGIS 10.3 or above, you can still install it on your machine, but you would need to have the .dll files of ArcObjects SDK for .NET of version 10.2 available.

The registrant package tool is not a replacement of ArcGIS Diagrammer as it can only report the information about the geodatabase contents (you cannot design a new geodatabase). However, this tool reports a lot of useful information about the contents of geodatabase as ArcGIS Diagrammer does. This means that you might not need to install ArcGIS Diagrammer if you are only interested in getting the HTML reports about the geodatabase contents.
I would like to see the information about X being reported, but the HTML report doesn't provide any information about it. Can you please add it?

Feel free to post an issue in this repository and I will see what's possible.
Why does it take less time for ArcGIS Diagrammer to generate HTML report about my geodatabase?

ArcGIS Diagrammer was built using fine-grained ArcObjects libraries which provides low-level access to the underlying geodatabase datasets and their properties. With this Python package, reading the geodatabase is done using arcpy Python package which makes it really easy to write and maintain this package, however there is a price to pay for that; it takes extra time to convert ArcObjects COM objects to Python objects and vice versa which results in longer processing time. Reading properties of geodatabase datasets with ogr happens much faster than when using arcpy, but you don't get all the properties exposed via this interface.

If you need to produce HTML reports fairly often and performance does matter to you, try to leave out some of the report options to save time. You could, for instance, skip reporting indexes and subtypes for every table and feature class if you have a large number of datasets in your geodatabase.
I have no Esri software and no GDAL/OGR installed. Can I generate the report of my SQL Server/Oracle/MySQL/PostgreSQL/etc database anyway?

No, you cannot because the package expects to be able to pull all the information about the tables and columns using either arcpy which comes with ArcGIS software or OGR which comes together with GDAL Python bindings. However, there are many other programs that will be able to generate the schema report among many other things. Take a look at SchemaSpy, for instance.

Report contents

General geodatabase overview
Enterprise geodatabase versions
Enterprise and local geodatabase replicas
Domains & coded values
Tables & Feature classes
Table & Feature class fields
Table & Feature class subtypes (arcpy only)
Table & Feature class indexes (arcpy only)

Added in v0.2:

Replicas and replicas' datasets (arcpy only)

Added in v0.3:

Versions in SDE geodatabases (arcpy only)

Added in v0.4:

Properties Attachments enabled and Attachments count for tables and feature classes (arcpy only)

Added in v0.5:

Relationship classes in geodatabases (arcpy only)

Added in v0.6:

Reporting more information for GD
