ooniprobix

Cross-platform GUI for OONIProbe report analysis

Installation from source, Debian Wheezy

OONIProbix has been successfully tested on Debian Wheezy.

After cloning our repo, you can download all the necessary librarires via apt-get

sudo apt-get install git
git clone https://github.com/AccessNow/ooniprobix.git
cd ooniprobix
sudo apt-get install libyaml-0-2 python-yaml python-wxgtk2.8

To run the program, type:
python ooniprobix.py

Basic usage

When OONIProbix starts, the main window lets you open a specific report file (Under "File") or a directory of report files. You can double click any of the reports to load them in a new window, and clicking a different report will bring it up in the same window in a different tab.

Filtering multiple entries

If you have a report with a lot of entries in it (e.g. an http_requests/tcp-connect test that checks for blocking/resets of multiple sites), select "Filter on field(s)" from the Options menu to generate a report with just the values of certain variables in the hierarchy for each entry.

For example, if we're looking at a large http_requests test report with a lot of sites, you can generate a report that lists the URL each entry tried to test with the body proportion field for each site by typing in input,report.body_proportion or selecting the same fields from the drop down menu.
The general syntax is:

top_item1,top_item2,top_item3.sub_a.sub_b

Where sub_a is below top_item 3 in the hierarchy.

Once the report is generated, you can export it to CSV by clicking "Export CSV".
