GEAK-v3

GEAK is an AI-powered framework for automated GPU kernel optimization, built on top of mini-SWE-agent.

It enables systematic, profiling-driven, and scalable optimization of GPU kernels — evolving from single-kernel tuning (v1/v2) to full repository-level autonomous optimization (v3).

Evolution: From Kernel-Level to Repo-Level Automation
Core Architecture
Getting Started
Features
Summary

Evolution: From Foundation to Platform

GEAK v1 — Foundation (Triton)

GEAK v1 established the foundation with Triton-based kernel generation.

Reflexion-based kernel generation
Instruction → Triton kernels
TritonBench / ROCmBench improvements

Outcome: AI viability proven — LLM-based agents can generate and improve GPU kernels.

GEAK v2 — Expansion (Agent Family)

GEAK v2 expanded into a multi-agent system for HIP kernel optimization.

OptimAgent: profiling-driven optimization with multi-offspring exploration
OpenEvolve: genetic optimization for kernel evolution
support HIP → HIP kernel optimization

Outcome: Scalable multi-agent system

GEAK v3 — Platform (L1 → L3)

GEAK v3 evolves into a unified platform supporting the full optimization stack.

Support L3 kernel optimization (repository-level, full lifecycle)
Reduce human intervention via closed-loop automation
Unified kernel optimization (test discovery, baselines, profiling, strategy execution, validation)

Outcome: Anyone can optimize kernels — from single-kernel tuning to autonomous repo-level optimization.

Core Architecture

End-to-End Optimization Engine

At its core, GEAK runs a fully autonomous optimization loop:

Test Detection → Baseline → Profiling → Strategy Planning → (Patch Generation → Validation) × N → Best-performing Kernel

Each optimization step is:

Correctness-verified
Performance-measured
Version-tracked

Tool-Augmented Intelligence Layer

GEAK v3 introduces a structured tool ecosystem that enhances agent reasoning and execution quality.

The system integrates:

Profiling for quantitative bottleneck identification (memory bandwidth, occupancy, register pressure, execution stalls)
Optimization Strategy Management for tracking explored techniques, marking successful/failed strategies, and prioritizing high-impact directions
Version & Patch Management for automatic diff tracking, benchmarking history, regression detection, and best-patch selection
Knowledge Retrieval for on-demand AMD/NVIDIA GPU knowledge retrieval during optimization

Parallel Exploration & Scaling

GEAK v3 supports parallel optimization agents. This parallel scaling:

Raises the optimization ceiling
Increases robustness of exploration
Reduces dependence on single optimization trajectories

Getting Started

Installation

git clone https://github.com/AMD-AGI/GEAK
cd GEAK
pip install -e .

# To use the Knowledge feature, also install the langchain dependencies
pip install -e '.[langchain]'

# Set model name and key

# Option 1: set a LiteLLM model + provider API key
export MSWEA_MODEL_NAME="openai/gpt-5"
export OPENAI_API_KEY="YOUR_KEY"

# Anthropic example
export MSWEA_MODEL_NAME="anthropic/claude-sonnet-4-5-20250929"
export ANTHROPIC_API_KEY="YOUR_KEY"

# Option 2: If you use AMD LLM Gateway (model_class: amd_llm)
export AMD_LLM_API_KEY="YOUR_KEY"

Usage

Basic (single-agent) GPU kernel optimization

# Interactive REPL
mini

# Run with a specific task
mini -t "fix the bug in main.py"

# Auto-execute mode (no confirmation needed)
mini --yolo

# Enable RAG knowledge retrieval
mini --rag

# Use specific config.yaml
mini --config geak.yaml \
  --task "Optimize the kernel in src/kernel.cpp" \
  --yolo

Parallel optimization (multiple agents + best patch selection)

Each agent works in an isolated git workspace
Patches and test results are saved separately
After all runs finish, GEAK automatically selects the best patch based on the specified metric

mini --config geak.yaml \
  --num-parallel 4 \
  --repo /path/to/kernel/repo \
  --task "Optimize block_reduce kernel" \
  --gpu-ids 0,1,2,3 \
  --metric "Extract Bandwidth in GB/s (higher is better)" \
  --yolo

Notes:

--num-parallel: number of optimization agents
--repo: required when --num-parallel > 1 (each agent uses an isolated git worktree)
--gpu-ids: comma-separated GPU IDs for agents
--metric: natural-language instruction for extracting/comparing metrics from test logs
--yolo: run end-to-end without interactive confirmation

Configuration

Loading Configurations

mini loads configs in layers:

base config: mini.yaml
template: mini_kernel_strategy_list.yaml (default)
user override: --config geak.yaml (final override)

This means you can configure tools and parallel defaults directly in geak.yaml.

RAG Configuration

File: rag_config.yaml — controls the RAG retrieval pipeline:

| Parameter | Description | |-----------|-------------| | retrieval.embed_top_k / bm25_top_k | Number of candidates from Embedding / BM25 retrieval | | retrieval.enable_bm25 | Whether to enable BM25 dual-path recall | | retrieval.mcp_top_k | Number of final results returned | | reranker.enable_reranker | Whether to enable re-ranking | | fusion.semantic_weight / bm25_weight | Fusion weights for Embedding and BM25 | | summary.enable_rag_subagent | Whether to enable LLM summarization | | debug.verbose | Whether to print verbose RAG tool logs |

Output & Artifacts

GEAK saves patches + test logs so results are reproducible.

Default output base: optimization_logs/
Auto-generated run directory: optimization_logs/<kernel_name>_<YYYYmmdd_HHMMSS>/
Parallel runs: subfolders parallel_0/, parallel_1/, ...

Typical structure (parallel run):

optimization_logs/<kernel>_<timestamp>/
├── parallel_0/
│   ├── patch_0.patch
│   ├── patch_0_test.txt
│   └── agent_0.log
├── parallel_1/
│   └── ...
├── best_results.json
└── select_agent.log

Features

Unit test discovery

If you pass --create-test, or you do not provide --test-command, GEAK will run a UnitTestAgent that tries to discover or create tests:

mini --config geak.yaml \
  --repo /path/to/kernel/repo \
  --create-test \
  --task "Optimize device_batch_memcpy kernel"

System Tools (built-in)

| Tool | Purpose | Key outputs | | --- | --- | --- | | profiling | Profile workload to identify bottlenecks | rocprofiler-compute summary | | strategy_manager | Track optimization strategies | .optimization_strategies.md | | save_and_test | Save patch and run test_command | patch_N.patch, patch_N_test.txt |

Best patch selection

After parallel runs finish, GEAK runs a selection agent that reads all test logs, extracts metrics, and writes best_results.json + select_agent.log.

Knowledge Base Retrieval

Integrates AMD AI DevTool for hybrid knowledge base retrieval (BGE Embedding + BM25 + Reranking), with built-in AMD GPU and NVIDIA GPU knowledge bases.

Knowledge Base Structure

knowledge-base/
├── amd-knowledge-base/
│   ├── layer-1-hardware/         # Hardware architecture
│   ├── layer-2-compute-stack/    # HIP, ROCm
│   ├── layer-3-libraries/        # rocBLAS, MIOpen, etc.
│   ├── layer-4-frameworks/       # PyTorch, TensorFlow
│   ├── layer-5-llm/              # LLM related
│   ├── layer-6-extended/         # Optimization guides
│   └── best-practices/
├── nvidia-knowledge-base/
├── comparisons/
└── INDEX.md

Knowledge Retrieval Architecture

Semantic + BM25 → RRF Fusion → BGE Reranker → Top K

Embedding: BAAI/bge-large-en-v1.5 (semantic recall)
BM25: Keyword-based recall
Fusion: RRF (Reciprocal Rank Fusion)
Reranker: BAAI/bge-reranker-large

Usage

1. Pre-download ROCm Library Source (Recommended)

git clone --depth 1 https://github.com/ROCm/rocm-libraries.git ~/.cache/rocm-libraries

2. Build Semantic Index (Required for First Use)

# Build index for all documents under knowledge-base/
python scripts/build_index.py --force

Index saved to ~/.cache/amd-ai-devtool/semantic-index/ by default:

index.faiss + index.pkl — FAISS semantic search index
bm25_index.pkl — BM25 keyword search index

Rebuild when: knowledge base documents are added/modified, or indexing logic changes.

Adding New Documents

Location: Place the file under the appropriate subdirectory (e.g., layer-6-extended/optimize-guides/*.md)

Format: Every .md file must include a YAML frontmatter:

---
tags: ["category1", "category2"]   # Required
priority: "L1-important"           # Required
source_url: "https://..."          # Required
rocm_version: "6.0+"              # Required
last_updated: 2026-01-14           # Required
---

Filename: Use English, make it descriptive (e.g., bf16-vector-load-store.md)
Quality: 800–1200 words, with at least 2 syntactically correct code examples
Rebuild index after adding: python scripts/build_index.py --force

3. Test Retrieval

python scripts/test_embedding_
