Self-supervised surround-view depth estimation with volumetric feature fusion

Jung-Hee Kim*, Junwha Hur*, Tien Nguyen, and Seong-Gyun Jeong - NeurIPS 2022
Link to the paper: Link

@inproceedings{kimself,
  title={Self-supervised surround-view depth estimation with volumetric feature fusion},
  author={Kim, Jung Hee and Hur, Junhwa and Nguyen, Tien Phuoc and Jeong, Seong-Gyun},
  booktitle={Advances in Neural Information Processing Systems (NeurIPS)}
  year = {2022},
}

Introduction

We introduce a volumetric feature representation for self-supervised surround-view depth approach, which not only outputs metric-scale depth and canonical camera motion, but also synthesizes a depth map at a novel viewpoint.
<img width="600" height="356" src="media/surround_fusion_feature.gif" /> <br> <img width="600" height="356" src="media/depth_synthesis.gif" />

Installation

• Install required libraries using the requirements.txt file.
  (Note that we leverage packent-sfm, dgp as submodules and therefore need to install required libraries related to the submodules.)
• To install both required library and submodules, you need to follow instruction below:

git submodule init
git submodule update
pip install -r requirements.txt

Datasets

DDAD

• DDAD dataset can be downloaded by running:

curl -s https://tri-ml-public.s3.amazonaws.com/github/DDAD/datasets/DDAD.tar

• Place the dataset in input_data/DDAD/
• We manually created mask image for scene of ddad dataset and are provided in dataset/ddad_mask

NuScenes

• Download NuScenes official dataset
• Place the dataset in input_data/nuscenes/
• Scenes with backward and forward contexts are listed in dataset/nuscenes/
• Scenes with low visibility are filtered in dataset/nuscenes/val.txt

Data should be as follows:

├── input_data
│   ├── DDAD
│   │   ├── ddad_train_val
│   │   ├── ddad_test
│   ├── nuscenes
│   │   ├── maps
│   │   ├── samples
│   │   ├── sweeps
│   │   ├── v1.0-test
|   |   ├── v1.0-trainval

Main Results

<table> <tr> <td>Model</td> <td>Scale</td> <td>Abs.Rel.</td> <td>Sq.Rel.</td> <td>RMSE</td> <td>RMSElog</td> <td>d_1.25</td> <td>d_1.25²</td> <td>d_1.25³</td> </tr> <tr> <td rowspan="2"><a href="https://drive.google.com/drive/folders/1UAPjm3pplVPkbS6jLsIFWDmsR8O8dX-1?usp=drive_link"> DDAD </a> </td> <td style="text-align:left">Metric</td> <td style="text-align:center">0.221</td> <td style="text-align:center">4.001</td> <td style="text-align:center">13.406</td> <td style="text-align:center">0.340</td> <td style="text-align:center">0.688</td> <td style="text-align:center">0.868</td> <td style="text-align:center">0.932</td> </tr> <tr> <td style="text-align:left">Median</td> <td style="text-align:center">0.221</td> <td style="text-align:center">3.884</td> <td style="text-align:center">13.225</td> <td style="text-align:center">0.328</td> <td style="text-align:center">0.692</td> <td style="text-align:center">0.877</td> <td style="text-align:center">0.939</td> </tr> <tr> <td rowspan="2"><a href="https://drive.google.com/drive/folders/1CipDGyLCYZcWKQSo1WlLbGsyn2ssL8dI?usp=drive_link"> NuScenes </a> </td> <td style="text-align:left">Metric</td> <td style="text-align:center">0.285</td> <td style="text-align:center">6.662</td> <td style="text-align:center">7.472</td> <td style="text-align:center">0.347</td> <td style="text-align:center">0.741</td> <td style="text-align:center">0.883</td> <td style="text-align:center">0.936</td> </tr> <tr> <td style="text-align:left">Median</td> <td style="text-align:center">0.258</td> <td style="text-align:center">4.282</td> <td style="text-align:center">7.226</td> <td style="text-align:center">0.329</td> <td style="text-align:center">0.735</td> <td style="text-align:center">0.883</td> <td style="text-align:center">0.937</td> </tr> </table>

Get Started

Training

Surround-view fusion depth estimation model can be trained from scratch.

• By default results are saved under results/<config-name> with trained model and tensorboard file for both training and validation.

Single-GPU <br> Training the model using single-GPU:
(Note that, due to usage of packnet-sfm submodule, userwarning repetitively occurs and therefore ignored while training.)

python -W ignore train.py --config_file='./configs/ddad/ddad_surround_fusion.yaml'
python -W ignore train.py --config_file='./configs/nuscenes/nusc_surround_fusion.yaml'

Multi-GPU <br> Training the model using Multi-GPU:

• Enable distributed data parallel(DDP), by setting ddp:ddp_enable to True in the config file
  • Gpus and the worldsize(number of gpus) must be specified (ex. gpus = [0, 1, 2, 3], worldsize= 4)
• DDP address and port setting can be configured in ddp.py

python -W ignore train.py --config_file='./configs/ddad/ddad_surround_fusion_ddp.yaml'
python -W ignore train.py --config_file='./configs/nuscenes/nusc_surround_fusion_ddp.yaml'

Evaluation

To evaluate the trained model from scratch, run:

python -W ignore eval.py --config_file='./configs/<config-name>'

• The model weights need to be specified in load: weights of the config file.

Evaluation results using the pretrained model can be obtained by using the following command:

python -W ignore eval.py --config_file='./configs/<config-name>' \
                         --weight_path='<pretrained-weight-path>'

Depth Synthesis

To obtain synthesized depth results, train the model from scratch by running:

python -W ignore train.py --config_file='./configs/ddad/ddad_surround_fusion_augdepth.yaml'

Then evaluate the model by running:

python -W ignore eval.py --config_file='./configs/ddad/ddad_surround_fusion_augdepth.yaml'

• The synthesized results are stored results/<config-name>/syn_results

License

This repository is released under the Apach 2.0 license.
